Basic Info.
Model NO.
KDZG
Selling Units
Single Item
Single Gross Weight
8.000kg
Packaging Details
Carton or Wooden Case
Measuring Range
Dew Point-80~+20 Csupport Ppmvetc.
Single Package Size
34X23X12cm
Working Temperature
-40c~+80
Power
Electronic
Customized Support
OEM,ODM,Obm,Software Reengineering
Resolution
Dew Point 0.1 C or 0.1ppm;
Transport Package
Carton or Wooden Case
Trademark
KDZD
Origin
Hubei, China
Packaging & Delivery
Package Size
50.00cm * 50.00cm * 50.00cm
Package Gross Weight
25.000kg
Product Description
| 1. Measuring range | dew point - 80 ~ + 20 ; (support ppmv, etc.); | |
| 2. Measurement accuracy | the measurement accuracy is better than ± 0.5 (within a certain range); | |
| When the dew point temperature is lower than 0 , the sensor output is frost point; | | |
| 3. Response time | 45 seconds for 63% and 90 seconds for 90% (+ 20 ) | |
| +20→-20 Td 5s[45s] | | |
| -20→-60 Td10s[240s]; | | |
| 4. Resolution | dew point 0.1 or 0.1ppm; | |
| 5. Repeatability | ± 0.5 | |
| 6. Gas flow | 0.4 1 (L / min); Adjust SF6 at 0.5 0.9l/min and H2 at 0.1 0.4l/min; | |
| 7. Pressure measurement | 0 1.0MPa | |
| 8. Probe protection | stainless steel sintered filter screen. | |
| 9. Working temperature | - 40 ~ + 80 | |
| 10. Operating environment | temperature: - 35 ~ + 60 ; Pressure: 0 ~ 20bar. | |
| 11. Electronic mass flowmeter. | | |
| 12. Working voltage | 110 ~ 220VAC, built-in rechargeable battery, AC and DC. | |
| 13. Lithium battery, AC / DC dual-use, automatic switching, overcharge and discharge protection function. | | |
| 14. Battery performance | charging time is more than 20 hours, and can be used for 10 hours | |
| 15. Size and weight | 250 × one hundred × 300mm3 3kg | |
Products Features
1. Portable design of the intelligent micro water measuring instrument: the instrument is lighter, portable and easy to use 2. Fast measurement: after the instrument is turned on, it does not need to wait for immediate measurement to quickly get the humidity value 3. Rapid gas saving: the gas consumption during measurement is only about 2L (101.2kpa) 4. Self locking joint: the self-locking joint imported from Germany is used, which is safe and reliable without air leakage 5. Data storage: the intelligent micro water meter is designed with large capacity and can store up to 50 groups of test data 6. Clear display: the LCD screen directly displays dew point, micro water (PPM), ambient temperature, ambient humidity, time and date, battery power, etc 7. RS232 interface: can be connected with serial port printer to print data 8. Built in power supply: built in 4ah rechargeable lithium battery, which can work continuously for 10 hours at a time
