Basic Info.
Model NO.
X020A, X030A
Location
Private Use
Start Mode
RFID Card, Password
Output
DC 20kw,DC30kw
Mounting
Portable, Moveable
Input Vovltage
AC380V/AC260-530V
Safety
Overcurrent,Undervoltage,Residualcurrent,Surgeprot
Ui Language
Russian, Japanese, English, Turkish, Germany
Transport Package
Wooden Case
Specification
650*322*428mm
Trademark
OEM
Origin
Guangdong, China
Product Description
Features:
•Simpleoperation,convenientinstallation,portableandmoveable
•Friendlyinteractioninterface,4.3-inchcolortouchscreen
•SupportEthernet/3G/4G/WIFI(optional)
•Supporttouchscreentostart/password/OCPP1.6J(optional)
•SupportGBT/CCS1/CCS2/CHAdeMOconnector(optional)
•TenSafetyProtection•Supportonlinedataupgrade.
•Friendlyinteractioninterface,4.3-inchcolortouchscreen
•SupportEthernet/3G/4G/WIFI(optional)
•Supporttouchscreentostart/password/OCPP1.6J(optional)
•SupportGBT/CCS1/CCS2/CHAdeMOconnector(optional)
•TenSafetyProtection•Supportonlinedataupgrade.
| S. NO. | Parameters | Requirements |
| General Requirements | ||
| 1 | Charger Capacity | 30KW |
| 2 | Model No. | ENC-DCX030A |
| Input Requirements | ||
| 3 | AC Supply System | Three-Phase, 5 Wire AC system |
| 4 | Nominal Input voltage | AC380V±15% |
| 5 | Input frequency | 45-65Hz |
| Environmental Requirements | ||
| 6 | Ambient Temperature Range | -25 to 55°C |
| 7 | Ambient Humidity | 5 to 95% |
| 8 | Storage temperature | -40 to 70°C |
| Mechanical Requirements | ||
| 9 | IP Ratings | IP 54 |
| 10 | Cooling | Air-cooled |
| Output Requirements | ||
| 11 | Number of outputs | 1 |
| 12 | Type of each output | DC200-750V |
| 13 | Output Current | Max.80 Amp |
| 14 | Output Connector Compatibility | IEC 62196 2017, IEC 61851 2017, SAE J1772, etc. |
| 15 | Power Factor | ≥0.99(50% load above) |
| User Interface & Display Requirements | ||
| 16 | Display | 4.3 Inches Touch Screen with Shell |
| 17 | User Authentication | QR Code/ Password(Optional) |
| 18 | Metering Information | Consumption Units |
| Communication Requirements | ||
| 19 | Communication between EVSE and Central Server | OCPP 1.6J Protocol (Optional) |
| 20 | Metering | Grid Responsive Metering as Per Units' Consumption of Each Vehicle |
| 21 | Interface between charger and CMS | Ethernet/3G/4G/WIFI (Optional) |
| Protection & Safety Requirements | ||
| 22 | Safety Parameters | Over Current, Under Voltage, Residual Current, Surge Protection, Leakage Protection, Short Circuit, Over Temperature, etc. |
